FLIR Systems Unveil Next-Gen FLIR A8580 Series Of HD Thermal Science Cameras

6 Feb 2020

Download PDF version

FLIR Systems, Inc. has announced the release of FLIR A8580 series of thermal science cameras - 1.3 megapixel, entry-level cooled camera designed for a wide range of industrial, military, science, and product research and development (R&D) applications.

This camera records blur-free images of high-speed targets, offering a wide range of precision, manual and motorized lenses, and also integrates seamlessly with the new FLIR Research Studio thermal analysis software, all providing the user with a high-end experience in a compact, easy-to-use camera.

FLIR A8580 series of thermal science cameras

The A8580 series includes four mid-wave infrared models as well as a long-wave model that provides better uniformity and stability through cool downs than other, similar LWIR cameras. This unique LWIR camera also offers wide temperature calibration ranges, reducing the need for repeated testing to fully measure a high dynamic scene, and fast integration times.

FLIR designed the A8580 with simplified connections and controls so it’s easy to set up and begin testing

All five models produce sharp, 1280×1024 thermal pixel imagery for a 30% improvement over previous FLIR compact science cameras. Users can maximize the number of pixels on their target through a suite of lens options, from the 200-millimeter telephoto lens to the 3x microscope lens for imaging extremely small targets.

Quick response times, advanced triggering options

The cameras’ quick response times and advanced triggering options help users record crisply focused images of fast-moving targets or accurately measure rapid changes in temperature. An internal filter mechanism allows the user to quickly switch between standard and high temperature ranges with a click of a button instead of manually changing neutral density filters.

Despite the advanced features, FLIR designed the A8580 with simplified connections and controls so it’s easy to set up and begin testing. The camera ramps up quickly and connects via Gigabit Ethernet or CoaXPress to a computer running FLIR Research Studio software. This included software allows users to view the live camera image, record the image stream, and evaluate thermal data from multiple FLIR cameras and recorded sources simultaneously.
