Protectowire FireSystems announces the release of the company’s first FM Approved and UL Listed Protectowire Interface Module PIM-530. The PIM-530 module was specifically engineered to simplify integration from our standard PHSC digital linear heat detectors into any addressable or conventional fire alarm system. Each PIM-530 interface module can supervise a single zone of their range of PHSC linear heat detectors.
The following benefits come standard with each module:
- Supervises 6500 feet (2000m) of standard PHSC linear detectors
- Modbus output via RS-485
- Relay contacts for universal compatibility to addressable modules or IDCs.
- Field configurable to support either a Class A or Class B configuration
- LCD screen and trackpad for easy programming
- Hardware available for use in classified hazards
- Integrated alarm point location
- 64 event history
- Optional NEMA-4X (IP66) enclosure
technology-driven marketplace
The input and feedback from the company’s distribution network, fire protection engineers, and end-users have been tremendously helpful in designing this product to meet the demands of the current, technology-driven marketplace. The PIM-530 module is available now for immediate release. For any communication about the company of the products, the team is always available on the numbers mentioned on the company’s website.
