In the Midwestern Illinois city of Rochelle, the local fire department took delivery of its first Toyne Apparatus, a fully customized rescue/pumper. The Rochelle Fire Department's (RFD) new rescue/pumper will replace an older fire truck built-in 1995 that had served the department for 26 years.

Built to take the call, the department’s latest fire apparatus addition is ready to protect the community. Established in 1877, the RFD has been serving the residents of Rochelle for nearly 145 years. The department has 34 firefighters on its roster and manages nine apparatus.

Building robust apparatus

In 2014, they responded to nearly 2,000 emergency calls. The department's firefighters will go through in-service training on their Toyne Apparatus before being officially put into service. "This is a highly capable rescue/pumper, and it's equipped with a wide variety of specialized hardware to assist the Rochelle Fire Department for a range of different emergencies," said Bill Bird, Toyne Product Support Coordinator. "We're proud to build an apparatus as robust as this one is."

The rescue/pumper was stall-built at the Toyne manufacturing facility in Breda, Iowa. Constructed with bolted painted stainless steel, the apparatus body is made to stand up to the elements. Toyne mounted the body onto a Spartan Metro Star ELFD chassis, and the cab boasts a 24-inch raised roof. Under the hood of this commanding apparatus is a 380-horsepower Cummins ISL9 engine and an Allison 3000 EVS transmission.

Vital hardware components

The rescue/pumper has plenty of storage options to accommodate different tools

On the inside of the cab, there is seating for up to six firefighters. Toyne outfitted the rescue/pumper with an array of vital hardware components that will be critical to operations and emergency response, such as a 360-degree backup camera system, FireCom in-cab intercom system, and an in-cab EMS storage compartment.

RFD's Toyne tailored apparatus was designed to be a multirole platform during emergencies. The rescue/pumper has plenty of storage options to accommodate different tools for fire and rescue situations. Quick access to their equipment is ensured with ROM painted roll-up doors, Toyne custom slide-out shelving, custom slide-out tool boards, and rear slide-in storage for ladders and pike poles. Designs called for installing an on-board SCBA air bottle refill system, air hose reels, a custom-built air-bag storage unit, and winch receptacles that are anchored on all four sides of the apparatus.

Addressing different emergencies

For fire suppression, Toyne added a 500-gallon UPF tank, 1,250-gallon-per-minute Hale Qmax enclosed side-mount pump, and an Elkhart Cobra Monitor with an 8598 extender. A Waterous Overboard Foam Power Fill and Waterous Aquis 6.0 Class-A/B foam systems elevate the department's ability to address different emergencies. The pump is controlled by a fire research pump boss pressure governor, and the tank level is monitored by an ICI SL Plus tank gauge.

Emergency lighting consists of a full suite of Whelen lights; including Whelen warning, PFP2 scene, PFH2 brow lighting, and LED arrow stick lighting. The body storage bays are wired with ILI LED strip compartment lighting. Dinges Fire Company from Amboy, Illinois, sold this Toyne rescue/pumper to the Rochelle Fire Department. As an authorized Toyne dealer, Dinges Fire Company serves fire departments throughout the state of Illinois.
