Bield Response24, Bield Housing & Care’s alarm receiving center (ARC) has become one of the first facilities of its kind to provide fire alarm system monitoring and management. Since 1971, Bield Housing & Care has remained committed to improving the quality of life for older people by offering a diverse range of services to enable them to achieve as much independence and life fulfillment as possible.

A not for profit organization, it is now one of the largest providers of housing and care in Scotland, with over 5,300 properties. Bield believes technology plays a vital role in helping it to accomplish these objectives and keep residents safe.

Bield Response24 Alarm Receiving Centre

Bield Response24 (BR24), the Alarm Receiving Centre (ARC), has been purpose built to monitor technology enabled care

The issue of life safety is a priority and Bield Response24 (BR24), the Alarm Receiving Centre (ARC), has been purpose built to monitor technology enabled care (such as personal alarms and warden call systems) and fire alarm systems in its housing & care developments throughout Scotland.

Like many other parts of the UK, unwanted alarm activations are a big problem in Scotland and cause a great deal of disruption. In 2014 the Scottish Fire and Rescue Service (SFRS) teamed up with partners including the Association of British Insurers (ABI), British Approvals for Fire Equipment (BAFE), the Building Research Establishment (BRE) and the Fire Industry Association (FIA) to undertake a detailed investigation.

Fire detection

As part of this work, in March 2015 it announced that it will no longer silence or reset systems after a call out to grouped housing developments, as doing so wipes any data that could provide reasons why it was erroneously asked to attend.

For Bield Housing & Care this was a costly problem, as it meant when a system required resetting a call had to be made to the fire alarm company responsible for the site, and an engineer had to drive to the location and physically press the silence and reset buttons on the fire detection control panel. In some instances this was a four or five hour return journey and would mean a bill of up to £200.

Rapid Fire Services collaborates with Gent by Honeywell

Glasgow based Rapid Fire Services was consulted to see if it could suggest some ideas about what could be done. A Gent by Honeywell approved system integrator; Rapid had no hesitation in recommending the use of Gent’s innovative graphics package – an invaluable software tool for any size of network that allows for complete management of the fire detection and alarm system from a central location.

The Gent software provides a graphical view of the entire system, enabling easy location of a fire in an emergency and allowing rapid decision making through event-based control of devices.

Fully integrated with Gent software

RFS fully integrated the Gent software into BR24’s ARC by having a device server fitted beside each Gent Vigilon fire alarm panel

Rapid Fire Services (RFS) fully integrated the Gent software into BR24’s ARC by having a device server fitted beside each Gent Vigilon fire alarm panel, which is given a unique IP address that enables it to communicate through the Internet. Personal alarm units are installed in the home and use a resident’s telephone line in the event of smoke/heat detection.

This allows the Emergency Call Advisors (ECA) at BR24 to engage in dialogue with the tenant to ascertain the reason behind the fire alert. The ECA then has 60 seconds to decide through discussion with the tenant if the SFRS is required.

Warden call systems

Warden call systems (WCS) are also used, although they do not offer the same facility to contact the tenant, as the WCS line is engaged with the fire detector call preventing speech module use.

With most grouped housing fire detection systems the ARC is only made aware of the main fire alarm activation, not the manual call point or smoke detector that activated the alarm. Therefore, the majority of SFRS calls made will identify the address but not the internal location details.

Remote access and monitor system

To avoid location issues, the Gent software enables BR24 to give precise location details within the dwelling when placing a 999 call, eliminating search time delays. Furthermore, manual call points or smoke detectors can be silenced while awaiting attendance, reducing anxiety levels to other tenants within the grouped housing development. This poses no threat to system functionality if a smoke is detected from another device.

40% of Bield’s developments can now be remotely accessed and monitored for fire and operational issues, while remote diagnostics ensure that when an engineer is required they have all the necessary replacement parts to repair any faults, saving costs on return visits.

Fire alarm systems

Assistance can be given to on-site staff who are experiencing problems with their fire alarm systems, fire alarm devices can be remotely adjusted for sensitivity and, of course, it can remotely silence and reset the systems whenever SFRS gives the authority to do so.

Gent by Honeywell is synonymous with quality and innovation in the fire detection and alarm industry. Honeywell Gent fire detection systems have been developed to the highest possible standards to deliver the most advanced fire detection and alarm system available in the market today. Gent exclusively supplies its equipment to partners who are selected for their ability to deliver the highest quality of service and solutions for a wide range of industrial applications.
